FPV VRX Video Transmission Module RX3364pro 3060-3500MHz

RX3364PRO
Receiving frequency range: 3060-3500MHz
Voltage Standing Wave Ratio: 2:1
Demodulation system: FM/PLL
IF: 480MHz
ANT. input impedance: 50Ω, Typ.
LO Frequency stabilization: ±200kHz

The modules are all designed with a single chip. The chip integrates VCO, PLL, broadband FM video demodulation and FM audio demodulation, making the module small in size, low in power consumption, high in sensitivity and the like. The module takes the form of patch package, occupying very small space of the whole machine. The application of this module is simply connected to the power supply, audio cable, video cable, connected to the antenna can receive sound, image signals. Our company can also customize the exclusive module according to the customer's requirements. Please call for more information.
